PIPER AIRCRAFT, INC.

PA-28-161, WARRIOR III

MAINTENANCE MANUAL

PAGE 1

Nov 30/062F3

24-50-00

ELECTRICAL LOAD DISTRIB

UTION

Component Loads

See Chart 1.

Duty Cycle Circuit / Circuit

Cont. Inter. Equipment Breaker (Amps) Optional

X Alternator Field 5 2.3

X Anti-Collision (Strobe) 5 3.5

X Auxiliary Vacuum Pump 20 5.0 X

X Cabin Dome Light 5 0.3

X Cockpit Flood Light 5 0.3

X Electric Clock - Negl. X

X Engine Gauge 3 0.2

X Fuel Pump 5 5.0

Instr. Panel/Switch Lights 7.5

X Panel Lights - 0.8

X Switch Lights - 0.8

X Landing Light 5 3.6

X Master Contactor - 0.5

X Pitot Heat 7.5 6.0 X

X Position (Nav) Lights 5 4.0

X Primer Valve - 0.4

X Radio Lights 5 0.5

X Recognition Lights 5 3.0 X

X Starter - 175.0

X Starter Contactor - 0.74

X Turn & Bank 5 0.3

Avionics (See Mfg's Installation Manual.)

CHART 1

ELECTRICAL SYSTEM COMPONENT LOADS
