PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 1
Nov 30/06
5H23
91-28-20
Fuel Pump
Figure 1
IN-LINE
FILTER
FUEL
PUMP
ELECTRICAL BUS
Q2A 20
Q2B 20
2
FUEL
PUMP
SWITCH
5A
1
3
44
P1
R1
Q2C 20
FUEL
PUMP
Q2F 20
Q2J 20
1
3
5
Q2D 20
11
32
22
Q2G 20
1010
P1
R1
Q2H 20
Q2K 20N
Q2E 20
PRIMER
SWITCH
PRIMER
SOLENOID
A
B
85423 F
104295 F
