Piper PA-28-161 Maintenance Manual

PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 1
Nov 30/06
4E3
52-30-00
CARGO
1. Baggage Door
A. Removal
With the door open remove the hinge pin from the hinge and remove the door.
B. Installation
Place the door in position so that the hinge halves are properly matched and install the hinge pin. It
will not be necessary to replace the hinge pin with a new pin if it is free of bends and wear.
2. Baggage Door Lock Assemb
ly
A. Removal
(1) With the door open remove the nut from the back of the lock assembly by use of a special
made wrench. (This tool may be fabricated from the dimensions given in Figure 1.)
(2) Remove the lock assembly through the front of the door.
B. Installation
(1) Place the lock into position for installation.
(2) Install the nut on the lock assembly and tighten with the use of a special wrench.
3. Baggage Door Hinge
A. Removal
(1) Remove the door from the airplane as described in Baggage Door - Removal, above.
(2) Remove the hinge half from the airplane or door by drilling out the rivets and removing the
hinge.
B. Installation
(1) Place the hinge halves together and install the hinge pin.
(2) Install the door into the closed position and drill the two end river holes and install the rivets.
(3) Operate the door and check for proper fit and installation. Drill the remaining holes and install
the rivets.

Piper PA-28-161 Specifications

General

Manufacturer	Piper Aircraft
Model	PA-28-161 Warrior II
Engine	Lycoming O-320-D3G
Horsepower	160 hp
Seating Capacity	4
Wingspan	35 ft (10.7 m)
Length	24 ft 0 in
Maximum Speed	127 knots
Cruise Speed	122 knots
Maximum Takeoff Weight	2, 325 lb (1, 055 kg)
Fuel Capacity	48 US gallons (182 L)
