Piper PA-28-161 Maintenance Manual

PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 1
Nov 30/06
1C13
5 - CONTENTS
CHAPTER 5 - TIME LIMITS / MAINTENANCE CHECKS
TABLE OF CONTENTS
SUBJECT SECTION PA
GE GRID NO.
GENERAL 5-00-00 1 1C15
TIME LIMITS 5-10-00 1 1C17
SCHEDULED MAINTENANCE 5-20-00 1 1C19
Description 1 1C19
Definitions 1 1C19
Inspection Requirements 3 1C21
Annual / 100 Hour Inspection 3 1C21
Progressive Inspection 3 1C21
Overlimits Inspection 3 1C21
Annual / 100 Hour Inspection Procedure 4 1C22
Scheduled Maintenance 7 1D1
Propeller Group 7 1D1
Engine Group 7 1D1
Cabin and Cockpit Group 9 1D3
Fuselage and Empennage Group 9 1D3
Wing Group 11 1D5
Landing Gear Group 12 1D6
Special Inspections 12 1D6
Operational Inspection 12 1D6
General 13 1D7
Notes 13 1D7
SPECIAL INSPECTIONS 5-30-00 1 1D13
Per Flight Hour 1 1D13
Per Calendar Year 2 1D14
Per Specific Operation / Operating Environment 4 1D16
High Dust or Industrial Pollution 4 1D16
High Salt or High Humidity 5 1D17
Extreme Cold 5 1D17
Soft or Unusual Terrain 6 1D18
UNSCHEDULED MAINTENANCE CHECKS
5-50-00 1 1E1
Lightning Strike 1 1E1
Engine Overtemp, Overtorque, or Sudden Stoppage 2 1E2
Severe Turbulence, Hard or Overweight Landing 2 1E2
Flaps Extended Above Maximum Flap Extension Speed (V
FE
) 3 1E3
Flood Damage, Immersion in Water 4 1E4

Piper PA-28-161 Specifications

General

Manufacturer	Piper Aircraft
Model	PA-28-161 Warrior II
Engine	Lycoming O-320-D3G
Horsepower	160 hp
Seating Capacity	4
Wingspan	35 ft (10.7 m)
Length	24 ft 0 in
Maximum Speed	127 knots
Cruise Speed	122 knots
Maximum Takeoff Weight	2, 325 lb (1, 055 kg)
Fuel Capacity	48 US gallons (182 L)
