PIPER AIRCRAFT, INC.
PA-28-161, WARRIOR III
MAINTENANCE MANUAL
PAGE 5
Nov 30/06
3I5
34-50-00
(a) Configuration Menu
The JUMP TO menu page provides the capability to select a configuration mode starting
page without having to step through all of the pages. Press the CRSR key and sequence
through to the desired section with the 8 and 9 keys. Jump to the selection by pressing the
CRSR key again with the desired selection highlighted. The FUNC key steps to the next
configuration page, after which the START/STOP key reverses until stopping at the JUMP
TO menu page. Following is a list of selections and their descriptions:
SELECTION DESCRIPTION
DIAGNOSTICS Jumps to Gray Code Input Page
DISPLAY/AUDIO Jumps to Audio Volume Page
I/O CONFIG Jumps to ARINC INPUT #1 Page
ACFT CONFIG Jumps to Operation Configuration #1 Page
(b) Refer to Charts 2-6 for required settings on the configuration pages.
(c) On the TEMPERATURE Page, select “NO” for SENSOR INSTALLED.
(d) MODE S Address (ICAO Aircraft Address Code) and FLIGHT ID Entry Page
When the unit is turned on for the first time, or an invalid address is recognized, the unit
will prompt the user to enter a valid aircraft address.
NOTE: U.S. registered aircraft ICAO Aircraft Address Code (ADDRESS HEX) is the
“N number” and is displayed as such on the ATC-601. On Non-U.S. registered
aircraft, verify only that the hexadecimal code displayed on ATC-601 matches the
“ADDRESS HEX” code programmed on the GTX-330.
1
U.S. Registered Aircraft
a
To highlight the “U.S. Tail #” address field, press the CRSR key one time.
b Enter the registration number using the number keys. Press the CRSR key to
select the numeric entry field. Press a key repeatedly to scroll through the
digit/alpha characters for that entry field.
c
Repeat step 2 until the complete number is entered.
d
When finished, press the CRSR key to accept the number entry.
e For entering the Flight ID number, press the CRSR key one time.
f Repeat steps 2 and 3.
g When finished, press the CRSR key to accept the number entry.
To Next Page
