4. Select the Pattern number: field.
1. Type in the number of the best aligned pattern.
2. Select OK.
3. Select Next to continue.
5. Repeat steps 3 and 4 to print the second vertical test pattern.
6. If the alignment was successful, a message appears indicating that the print heads have been
vertically aligned to print on envelopes. Select Next to continue to the horizontal alignment.
7. Place an envelope on the feed deck and select Start to print the first horizontal test pattern.
8. Select the Pattern number: field.
a. Type in the number of the best aligned pattern.
b. Select OK.
c. Select Next to continue.
9. Repeat steps 7 and 8 to print the second horizontal test pattern.
10. If the alignment was successful, a message appears indicating that the print heads have been
aligned to print on envelopes. Select Done.
Tape alignment only
1. Select Tape to print the first vertical test pattern.
a. Select the Pattern number: field.
b. Type in the number of the best aligned pattern.
c. Select OK.
d. Select Next to continue.
2. Repeat step 1 to print the second vertical test pattern.
3. If the alignment was successful, a message appears indicating that the print heads have been
vertically aligned to print on tape. Select Next to continue to the horizontal alignment.
4. Select Tape to print the first horizontal test pattern.
a. Select the Pattern number: field.
b. Type in the number of the best aligned pattern.
c. Select OK.
d. Select Next to continue.
5. Repeat step 4 to print the second horizontal test pattern.
6. If the alignment was successful, a message appears indicating that the print heads have been
aligned to print on tape. Select Done.
Maintenance
