User’s Manual of GT-915A
21
Caution:
1. Never push the converter into the slot with force; it could damage the chassis.
2. The Media Converter Chassis supports hot-swap; there is no need
to turn off the whole
chassis before sliding in the new converter.
2.2.4 Installing the SFP Transceiver
The sections describe how to insert an SFP transceiver into an SFP slot.
The SFP transceivers are hot-pluggable and hot-swappable. You can plug-in and out the transceiver to/from any SFP port
without having to power down the Managed Media Converter, as the Figure 2-3 shows..
Figure 2-3: Plug-in the SFP Transceiver
 Approved PLANET SFP Transceivers
PLANET Managed Media Converter supports both Single mode and Multi-mode SFP transceiver. The following list of approved
PLANET SFP transceivers is correct at the time of publication:
Gigabit SFP Transceiver Modules
MGB-GT
SFP-Port 1000BASE-T Module
MGB-SX
SFP-Port 1000BASE-SX mini-GBIC module - 550m
MGB-SX2
SFP-Port 1000BASE-SX mini-GBIC module - 2km
MGB-LX
SFP-Port 1000BASE-LX mini-GBIC module - 20km
MGB-L40
SFP-Port 1000BASE-LX mini-GBIC module - 40km
MGB-L80
SFP-Port 1000BASE-LX mini-GBIC module - 80km
MGB-L120
SFP-Port 1000BASE-LX mini-GBIC module - 120km
MGB-LA10
SFP-Port 1000BASE-LX (WDM,TX:1310nm) mini-GBIC module - 10km
MGB-LB10
SFP-Port 1000BASE-LX (WDM,TX:1550nm) mini-GBIC module - 10km
MGB-LA20
SFP-Port 1000BASE-LX (WDM,TX:1310nm) mini-GBIC module - 20km
MGB-LB20
SFP-Port 1000BASE-LX (WDM,TX:1550nm) mini-GBIC module - 20km
MGB-LA40
SFP-Port 1000BASE-LX (WDM,TX:1310nm) mini-GBIC module - 40km
MGB-LB40
SFP-Port 1000BASE-LX (WDM,TX:1550nm) mini-GBIC module - 40km
MGB-LA80
SFP-Port 1000BASE-LX (WDM,TX:1490nm) mini-GBIC module - 80km
