User’s Manual of GT-915A
55
4.3.1.2 SFP Module Information
This page shows the operational status, such as the transceiver type, speed, wavelength, optical output power, optical input
power, temperature, laser bias current and transceiver supply voltage in real time. The SFP Module Information page is shown
in Figure 4-30.
Figure 4-30: SFP Module Information
Object Description
• Port
Display per port list.
• Type
Display the type of current SFP module; the possible types are:
 1000BASE-SX/LX
 100BASE-TX
• Speed
Display the speed of current SFP module; the speed value or description is
obtained from the SFP module. Different vendors SFP modules might show
different speed information.
• Wave Length(nm)
Display the wavelength of current SFP module; the wavelength value is obtained
from the SFP module. Use this column to check if the wavelength values of two
nodes match while the fiber connection fails.
• Distance (m)
Display the support distance of current SFP module; the distance value is
obtained from the SFP module.
• Temperature (C)
– SFP DDM Module Only
Display the temperature of current SFP DDM module; the temperature value is
gotten from the SFP DDM module.
• Voltage (V)
– SFP DDM Module Only
Display the voltage of current SFP DDM module; the voltage value is gotten from
the SFP DDM module.
• Current (mA)
– SFP DDM Module Only
Display the ampere of current SFP DDM module; the ampere value is gotten
from the SFP DDM module.
• TX power (dBm)
– SFP DDM Module Only
Display the TX power of current SFP DDM module; the TX power value is gotten
from the SFP DDM module.
• RX power (dBm)
– SFP DDM Module Only
Display the RX power of current SFP DDM module; the RX power value is gotten
from the SFP DDM module.
