User’s Manual of GT-915A
• Link Transparent
Provide disable or enable the Link Transparent function. Default mode is Disable.
• Link Transparent
Result
Display the link transparent result.
• Apply button
Press this button for save current configuration of Managed Media Converter.
Table 4-32 Descriptions of the Local TS-1000 OAM Setup Web Page Screen Objects
4.3.2.2 Remote OAM TS-1000 Configuration
The Remote TS-1000 OAM Setup is an advanced remote device monitor feature that allows you to Remote monitor and
automatic notify status indication.
Remote monitor
1. User instructs center Media Converter to issue a status notification request frame defined in TS-1000 to get status
of terminal Media Converter.
2. Terminal Media Converter receives the status notification request frame and sends out status response frame,
which carries its current status.
Autonomous notification
1. Terminal Media Converter notifies the center Media Converter autonomously with a status notification indication, if
any change occurs in the status monitored internally by the terminal Media Converter.
2. Center Media Converter if support Option A, notifies the terminal Media Converter autonomously with a status
notification indication, if any change occurs in the status monitored internally by the center Media Converter.
This function provides Remote TS-1000 OAM Setup of Managed Media Converter. Press the “Apply” button to save the
current configuration of Managed Media Converter. The screen in Figure 4-33 appears.
Figure 4-33 GT-915A Remote TS-1000 OAM Setup Web Page screen
Notice:
Please use the PLANET GST-80x and GT-91x as the Remote device.
