4.4.3 Bandwidth Control
This page allows you to configure the incoming and outgoing bandwidth control settings for all switch ports as the bandwidth
control screen in Figure 4-59 appears.
Figure 4-59: Bandwidth Control Configuration Page Screenshot
The page includes the following fields:
Object
Description
• Port Selection Select specific port for incoming and outgoing bandwidth control settings.
• Ingress Rate (kbps)
•
(1-1000000)
Controls the rate (unit: kbps) for the ingress rate. This value is restricted to
1-1000000. The default value is Unlimited.
• Egress Rate (kbps)
•
(1-1000000)
Controls the rate (unit: kbps) for the egress rate. This value is restricted to
1-1000000. The default value is Unlimited.
• Port Display per port list.
• Ingress Rate (kbps) Display per port ingress rate setting value.
• Egress Rate (kbps) Display per port egress rate setting value.
Buttons
: press this button to take effect.
: press this button to refresh information.
