Planet GT-915A User Manual

User’s Manual of GT-915A
80
The page includes the following fields:
Buttons
: press this button to take effect.
: press this button to refresh current status.
Object
Description
• Port Selection
This column provides selecting specific port for LLDP Port Settings function.
•
Admin Status
This column provides displaying and selecting the Admin status of LLDP and
the available options are :
Disable
The Managed Media Converter will not send out LLDP information, and will
drop LLDP information received from neighbors.
Rx Only
The Managed Media Converter will not send out LLDP information, but LLDP
information from neighbor units is analyzed.
Tx Only
The Managed Media Converter will drop LLDP information received from
neighbors, but will send out LLDP information.
Tx & Rx
The switch will send out LLDP information, and will analyze LLDP information
received from neighbors.
• Port Description
This column provides displaying and configuring enable or disable the Port
Description function.
When enabling the "Port Description", the LLDP information will be transmitted.
• System Name
This column provides displaying and configuring enable or disable the System
Name function.
When enabling the "System Name", the LLDP information will be transmitted.
• System Description
This column provides displaying and configuring enable or disable the System
Description function.
When enabling the "System Description”, the LLDP information will be
transmitted.
• Capability
This column provides displaying and configuring enable or disable the
Capability function.
When enabling the "Capability”, the LLDP information will be transmitted.
• Management Address
This column provides displaying and configuring enable or disable the
Management Address function.
When enabling the "Management Address”, the LLDP information will be
transmitted.
• Port
Display per port list.
