2.1.1 Panel Layout
Figure 2-2 and Figure 2-3 show the hardware interface of the WDAP-C1750.
Hardware Interface
Figure 2-2 WDAP-C1750 Front Panel Layout
Figure 2-3 WDAP-C1750 Side Panel Layout
