User Manual of WDAP-C1750
-34-
5.3 Wireless Settings
5.3.1 2.4GHz 11bgn Basic Settings
The “2.4GHz 11bgn” menu allows you to view and configure information for your access point’s 2.4GHz wireless
network across four categories: Basic, Advanced, Security and WDS.
Figure 5-9 2.4GHz Wireless Settings
The page includes the following fields:
Object Description
Wireless
Enable or disable the access point’s 2.4GHz wireless radio.
When disabled, no 2.4GHz SSIDs will be active.
Band
Select the wireless standard used for the access point. Combinations
of 802.11b, 802.11g and 802.11n can be selected.
Enable SSID
Number
Select how many SSIDs to enable for the 2.4GHz frequency from the
drop-down menu.
A maximum of 16 can be enabled.
SSID#
Enter the SSID name for the specified SSID (up to 16).
The SSID can consist of any combination of up to 32 alphanumeric
characters.
