User Manual of WDAP-C1750
-54-
Session Timeout
Set duration of session timeout in seconds between 0 and 86400.
Accounting
Enable or disable RADIUS accounting.
Accounting Port
When accounting is enabled (above), set the UDP port used in the
accounting protocol of the RADIUS server.
Value must be between 1 and 65535.
5.3.11 Internal Server
The access point features a built-in RADIUS server which can be configured as shown below.
Figure 5-27 Internal Server
The page includes the following fields:
Object Description
Internal Server
Check/uncheck to enable/disable the access point’s internal RADIUS server.
EAP Internal
Authentication
Select EAP internal authentication type from the drop down menu.
EAP Certificate
File Format
Displays the EAP certificate file format: PCK#12(*.pfx/*.p12)
EAP Certificate
File
Click “Upload” to open a new window and select the location of an EAP
certificate file to use. If no certificate file is uploaded, the internal RADIUS
server will use a self-made certificate.
Shared Secret Enter a shared secret/password for use between the internal RADIUS server
and RADIUS client.
The shared secret should be 1 to 99 characters in length.
Session Timeout Set a duration of session timeout in seconds between 0 to 86400.
Termination
Action
Select a termination-action attribute: “Reauthentication” sends a RADIUS
request to the access point, “Not-Reathentication” sends a default
termination-action attribute to the access point, “Not-Send” no
termination-action attribute is sent to the access point.
