Chapter C - ERROR MESSAGES

ProMax X-ray unit with Dimax3 C-9

HELP AND ERROR MESSAGE SHORT-FORM TABLES

Technical Manual

1.5 Feedback errors (4xx)

Error

code

Explanation Comments

E401 Tube head offsets KVPOS failure - shorted Exposure not possible. Check the

cabling between the FBK and the

CAM PCB. Check also the func-

tionality of the FBK PCB.

E402 KVPOS failure - out of bounds Exposure not possible. Check the

cabling between the FBK and the

CAM PCB. Check also the func-

tionality of the FBK PCB.

E403 KVNEG failure - shorted Exposure not possible. Check the

cabling between the FBK and the

CAM PCB. Check also the func-

tionality of the FBK PCB.

E404 KVNEG failure - out of bounds Exposure not possible. Check the

cabling between the FBK and the

CAM PCB. Check also the func-

tionality of the FBK PCB.

E405 MAPOS failure - shorted Exposure not possible. Check the

cabling between the FBK and the

CAM PCB. Check also the func-

tionality of the FBK PCB.

E406 MAPOS failure - out of bounds Exposure not possible. Check the

cabling between the FBK and the

CAM PCB. Check also the func-

tionality of the FBK PCB.

E407 MANEG failure - shorted Exposure not possible. Check the

functionality of the FBK PCB.

E408 MANEG failure - out of bounds Exposure not possible. Check the

functionality of the FBK PCB.

E409 FILAMENT failure - out of bounds Exposure not possible. Check the

functionality of the FBK PCB.

E411 Tube head signals kV-feedback imbalance Exposure interrupted.

E412 mA-feedback imbalance Exposure interrupted.

E413 tube head grounding error Exposure not possible.

E414 temperature measurement error (signal

out of bounds)

Exposure not possible. Check the

temperature measurement sen-

sor and the FBK PCB.

E415 tube head electronics supply voltage

error

Check the FBK PCB and the

cabling between the FBK and the

CAM PCB.

E416 Tube head not calibrated Exposure not possible. Perform

the preheat calibration again.

Check the functionality of the

FBK PCB.

E417 Tube head is of non-supported type

(reserved)

Exposure not possible.
