Planmeca ProMax X-ray User Manual

Chapter H - CEPHALOSTAT
ProMax X-ray unit with Dimax3 H-59
DETACHING AND ATTACHING THE SENSOR HEAD
Technical manual
3.2 Cephalostat with fixed sensor head - removing and
attaching the sensor head
Unscrew the bottom cover plate attachment screw with the 4mm Allen key and remove the
cover plate.
Figure 104
Unscrew the attachment screw of the back cover with the 4mm Allen key and slide the cover
from its position.
Figure 105
