Planmeca ProX Technical Manual

4 SERVICE MODE
Technical manual Planmeca ProX 19
4 SERVICE MODE
4.1 Control panel
4.2 How to enter/exit service mode
Press and hold down the select key for 4 seconds.
Press and hold down the Mode key for more than 2 seconds, until the four uppermost
preprogrammed setting indicator lights come on.
To exit service mode
Press the Mode key for 2 seconds.
NOTE
The service mode parameters 1 - 13 and 20 are for factory use only. Do NOT adjust these
parameters.
66
0.25
SELECT key
mA display
Parameter adjustment keys
Pre-programmed setting
keys and indicator
lights
Preprogrammed setting keys
and indicator lights
Adult/child selection key
and indicator lights
Ready indicator light
Exposure warning
indicator light
Exposure key
66
0.250
6
kV display
Time display
MODE key

Planmeca ProX Specifications

General

Type	Intraoral X-ray
Tube current	7 mA
Imaging Technology	Digital
Focal spot	0.4 mm
X-ray generator	High-frequency
Power Requirements	100–240 V AC, 50/60 Hz
Tube voltage	60-70 kV
