10 PARTS REPLACEMENT & REPAIR
Technical manual Planmeca ProX 45
10 PARTS REPLACEMENT & REPAIR
Make sure that the power supply is switched off before starting parts replacement.
10.1 Removing generator housing
1. Disconnect the X-ray unit from the mains or switch off the power supply.
2. Unscrew four attachment screws and remove the generator housing.
Mounting_generator_housing.eps
