Planmeca ProX Technical Manual

4 SERVICE MODE
22 Planmeca ProX Technical manual
4.6 Dimming displays
Enter the service mode according to the instruction given in section 4.2 “How to enter/exit
service mode” on page 19.
Press the parameter adjustment up key until the parameter number 16 appears on the kV
display.
The number indicating the brightness of the displays (from 1 to 5, factory default is 5) is
shown on the time display.
Press the Select key until the number starts to blink, and the value can now be changed
with the parameter adjustment keys.
Accept the new setting by pressing the Select key.
To exit the service mode press the Mode key for 2 seconds.
4.7 Duration of displays dimming time-out
Enter the service mode according to the instruction given in section 4.2 “How to enter/exit
service mode” on page 19.
Press the parameter adjustment up key until the parameter number 17 appears on the kV
display.
The number indicating the time-out value (0, 1, 2, 3, 4, 5) is shown on the time display.
The time-out values are: 0 = no dimming, 1 = 1 min., 2 = 2 min., 3 = 5 min., 4 = 20 min. and
5 = 60 min. Factory default is 1.
Press the Select key until the number starts to blink, and the value can now be changed
with the parameter adjustment keys.
Accept the new setting by pressing the Select key.
To exit the service mode press the Mode key for 2 seconds.
Parameter adjustment up -key
16
5
Parameter adjustment keys
Select key
Parameter adjustment up -key
17
0
Parameter adjustment keys
Select key

Planmeca ProX Specifications

General

Type	Intraoral X-ray
Tube current	7 mA
Imaging Technology	Digital
Focal spot	0.4 mm
X-ray generator	High-frequency
Power Requirements	100–240 V AC, 50/60 Hz
Tube voltage	60-70 kV
