Technical manual Planmeca ProX 5
1.4 Technical specifications
Generator Constant potential, microprocessor controlled,
operating frequency 66 kHz
X-ray tube Toshiba D-041SB
Focal spot size 0.4 mm according to IEC 60336
Cone diameter 60 mm (2.36 in.)
Rectangular 33 x 43 mm (1.30 x 1.69 in.)
Max. symmetrical radiation field ø 60 mm at SSD 200 mm
ø 60 mm at SSD 300 mm
according to IEC 806
Total filtration min. 2.5 mm Al equivalent at 70 kV
according to IEC 60522
Inherent filtration 1 mm Al equivalent at 70 kV
according to IEC 60522
Anode voltage 2-8 mA: 60, 63, 66, 70 kV, ±2 kV
Anode current 8, 7, 6, 5, 4, 3, 2 mA ±(5% + 0.2 mA)
Target material Tungsten
Target angle 12.5°
Exposure times 0.01- 2 sec. ±(5% + 0.001 sec.), 24 steps
Reference current time product 8 mAs at 70 kV, 8 mA, 1 sec.
Lowest current time product 0.02 mAs at 2 mA, 0.01 sec.
Max. nominal anode voltage 70 kV
Power input 1000 VA (220-240 V)
890 VA (100-115 V)
Max. electrical output 560 W at 70 kV, 8 mA
Electrical output at 0.1 sec. 560 W at 70 kV, 8 mA
Max. loading energy 1987 mAs/h at 70 kV
SID (SID = source - image
receptor distance)
min. 200 mm (8 in.)
SSD (Source-Skin Distance)
Standard/Long
Long with rectangular collimator
200 mm (8 in.)/300 mm (12 in.)
306 mm (12.04 in.)
Mains voltage 100 V~/110-115 V~/220-240 V~
Apparent resistance 0.3 ohms 100-115 V~ /0.8 ohms 220-240 V~
Mains frequency 50/60 Hz
Fusing units with 100V~ or 110-115V~ voltage
setting: 15AT, 250V, slow blow (6.3x32mm)
(special fuse, manufacturer Bussmann,
type MDA)
units with 220-240V~ voltage setting:
8AT, 250V, slow blow (6.3x32mm)
(special fuse, manufacturer Bussmann, type MDA)
Duty cycle 1:13,5, at least 6s. automatic control
Electrical classification Class I Type B
