1 GENERAL & TECHNICAL DATA
6 Planmeca ProX Technical manual
Mechanical data
Environmental requirements
External mains fuse recommendation
The recommendation for the external mains fuses are:
• units with 100V~ or 115V~ voltage setting: 16A, time lag
• units with 220-240V~ voltage setting: 10A, time lag
No other equipment should be connected to the same fused mains line as the x-ray unit. In
some countries an additional external fault current guard is also required.
Original manufacturer
PLANMECA Oy, Asentajankatu 6, FIN-00880, Helsinki, FINLAND
phone: +358-20-7795 500
Weight total 33 kg (73 lbs)
tube head
4.2 kg (9.3 lbs) with standard cone
4.5 kg (10 lbs) with long cone
Color RAL 9016
Ambient temperature operating +5°C - +40°C
storage -10°C - +50°C
transport
-10°C - +50°C
Humidity 25% - 75%
Atmospheric pressure range 700 hPa - 1060 hPa
