9 MECHANICAL ADJUSTMENTS
Technical manual Planmeca ProX 43
9.2 Adjusting rotational friction of bracket arm
Adjust the friction with one adjustment screw located below the arm using a 3 mm Allen
key. Tightening the screw will increase the friction.
9.3 Adjusting tube head’s rotational friction
Adjust the friction with one adjustment screw located below the joint using a 3 mm Allen
key. Tightening the screw will increase the friction.
