Polaris A12MH46AX

5.25
BODY / STEERING / SUSPENSION
5
9923412 - 2012 Sportsman 400/500 and EFI Tractor Service Manual
© Copyright 2011 Polaris Sales Inc.
Sportsman Rear Suspension Assembly
Upper Control Arm
Lower Control Arm
Bushings
Rear Compression Spring
Preload Adjustment Cam
Wheel Bearing Carrier
Boot Shield
37 ft. lbs.
(50 Nm)
(50 Nm)
37 ft. lbs.
(50 Nm)
37 ft. lbs.
50 ft. lbs.
(69 Nm)
50 ft. lbs.
(69 Nm)
37 ft. lbs.
(50 Nm)
37 ft. lbs.
(50 Nm)
37 ft. lbs.
(50 Nm)
