FINAL DRIVE
7
9923412 - 2012 Sportsman 400/500 an
d EFI Tractor Service Manual
© Copyright 201
1 Polaris Sales Inc.
Gearcase Inst
allation
1.
To install gearcase, reverse removal proced
ures.
Use a new roll pin in front prop shaft.
2.
Torque mo
unting bolts
in skid plat
e to
30 ft.lbs. (41
Nm)
.
3.
Add the proper lubricant
to the front gear
case. Ch
eck
d
rain plug for p
roper torque. Refer
to Chapter 2
for
fluid fill and change information.
=
T
Gearcase Mounting Bolt Torque
:
30 ft. lbs. (41 Nm)
New Roll Pin
262
264
