8.2
TRANSMISSION
9923412 - 2012 Sportsman 400/500 and EFI Tractor Service Manual
© Copyright 2011 Polaris Sales Inc.
TRANSMISSION - GENERAL
Torque Specifications
Special Tools
SPX Corporation - 1-800-328-6657 or http://
polaris.spx.com
Lubrication
Refer to Chapter 2 for transmission lubricant type and
capacity.
COMPONENT FT. LBS.
(IN.LBS.)
NM
Transmission Case Bolts 25-30 36-43
Bell Crank Nut 12-18 17-26
Transmission Fill/Drain Plug 20-25 29-36
Trans. Mounting Bolts 37-40 50-57
Gear Sector Cover 8-12 11-17
Oil Deflector Screws (20-30) 2-3.6
Snorkel Torx Screw 8-12 11-17
Bearing Cover 8-12 11-17
Carrier Cover 23-27 33-39
Shift Fort Retainer Screws 8-12 11-17
Park Plate 8-12 11-17
PART NUMBER
TOOL
DESCRIPTION
2871695 (
Part of 2871702 Kit) Backlash Setting Tool
2871698 (
Part of 2871702 Kit)
Rear Output Seal
Driver
2871699 (
Part of 2871702 Kit)
Rear Driveshaft Seal
Guide
2871282
Bearing Seal Driver
(
50 mm)
