8.10
TRANSMISSION
9923412 - 2012 Sportsman 400/500 and EFI Tractor Service Manual
© Copyright 2011 Polaris Sales Inc.
2012 Sportsman Transmission Exploded View, Continued
Ref. Qty. Description Ref. Qty. Description
1.
20 Screw
45.
1 Shift Drum
2.
2 Triple Lip Seal
46.
1 Sector Gear, 31 T
3.
1 LH Gearcase
47.
1 Shift Shaft
4.
2 Ball Bearing
48.
1 O-Ring
5.
1 Silent Chain
49.
1 Detent Pawl
6.
1 RH Gearcase
50.
1 Compression Spring
7.
2 Ball Bearing
51.
1 Sector Gear Cover
8.
1 Sprocket, 19 T
52.
1 Bellcrank
9.
1 Oil Deflector
53.
1 Lock Nut
10.
2 Screw
54.
1 Shift Switch
11.
1 Output Gear, 91 T
55.
1 Retaining Ring
12.
1 Retaining Ring
56.
1 Sector Gear, 16 T
13.
9 Screw
57.
1 Detent Star
14.
1 Bearing Cover
58.
1 O-Ring
15.
2 Retaining Ring
59.
1 Snorkel Shaft
16.
1 Shim
60.
1 Ball Bearing
17.
1 Ball Bearing
61.
1 Retaining Ring
18.
1 Center Drive Shaft
62.
1 Snorkel Tube
19.
1 Retaining Ring
63.
5 Screw
20.
1 Thrust Washer
64.
1 Shim
21.
1 Gear, 36 T
65.
1 Retaining Ring
22.
1 Needle Bearing
66.
1 Triple Lip Seal
23.
1 Washer
67.
1 Vent Tube
24
1 Engagement Dog
69.
2 Dowel Pin
25.
1 Engagement Dog
70.
1 Plug
26.
2 Retaining Ring
71.
2 Compression Spring
27.
2 Washer
72.
2 Retaining Ring
28.
1 Sprocket, 38 T
73.
2 Cup Washer
29.
1 Reverse Shaft, 26 T
74.
1 Retaining Ring
30.
1 Gear, 33 T
75.
1 Shim
31.
1 Shift Collar
76.
1 Needle Bearing
32.
1 Park Plate
77.
1 Speed Sensor
33.
2 Ball Bearing
78.
1 O-Ring
34.
1 Seal
79.
1 Output Shaft
35.
2 Ball Bearing
84.
1 Lockout Disc
36.
1 Input Shaft
85.
1 Magnetic Plug
37.
1 Chain
86.
38.
2 Shift Fork
87.
39.
2 Compression Spring
40.
1 Shift Rail
41.
1 Tensioner Pin
42.
1 Torsion Spring
43.
1 Chain Tensioner Cam
44.
1 Chain Tensioner Shoe
