THE ART OF WELDING
P6 HW
18-100 PN-0110008 Rev. 12
Basic design3. 3. 1.
The welding set contains the power source, all control
electronics and the torch cooling. All connections are
made on a connector panel situated at the front of
the power source.
The front panel also supports the printer and connec-
tions for the USB key and the RJ45 link for connect-
ing a PC.
There is a touchscreen mounted on top of the power
source for programming and monitoring of the weld
cycles.
The power source is fi tted with a 2-metre long power
supply cable.
1 Protection for programming screen 4 RJ45 connection
2 Screen and touchscreen (option) 5 USB connection
3 Printer (option) 6 Connection panel
Technical data for the P6 HW3. 3.
