THE ART OF WELDING
P6 HW
PN-0110008 Rev. 12 77-100
Spare parts of the power source6. 2. 5.
Fig 6.9 to Fig 6.11
Item. Order Code Description
1 00629085 Gas fl ow rate safety device
2 9000629198 Water fl ow rate safety device
3 0028219100 Adaptation of "hot wire" source
4 9000629189 Water temperature safety device
5 9000699063 Coolant fi lter housing with stainless fi lter element
6 9000699064 Sieve fi lter element (stainless)
7 9000629157 "Hot wire" source, 140A
8 9000629174 Gas solenoid valve 24 V
dc
9 0028009100 Sequencer 1 module and Sequencer 2 module
10 0028019100 Rotation or wire feeding module
11 0028029400 Welding current source module
12 0028069100 LVDS screen module
13 0028279100 Welding source adaptation
14 0028229200 motor inductor interface
24 9000629245 Source 520 A
15 0028029200 "Hot wire" source module
16 9000629184 Printer
17 00530054 Fuse FU1 (4 AT)
18 0028039100 AVC/oscillation module
19 0028079100 Arc voltage measurement module
20 0021700771 "Hot wire" source interface
21 0025069122 Earth cable 120 mm²
22 64599801 Hot wire source earthing cable
23 9000629221 Switch (without emergency stop)
24 9000629245 Source 520 A
- 9000629140 Switch self-holding (with emergency stop)
- 9000590068 Roll of thermal printer paper 57 x 50
- 75110071 Coolant for external coolant unit
- 75501002 Pressure-reducing valve with fl owmeter Argon France
- 71701418 Pressure-reducing valve with fl owmeter Argon Export
- 71701421 Pressure-reducing valve with fl owmeter argon/hydrogen
0023000901 A manual torch adaptater
