Remote control unit4. 4. 3.
Functions of the components4. 4. 3. 1.
Item Function
AF 1
4 line 20 character backlight display.
V 1
Red indicator light for simulation cycle.
V 2
Green indicator light for cycle with arc.
V 3
Green indicator illuminated: Increment actions
on low level.
V 4
Green indicator illuminated: Increment actions
on high level.
V 3 +
V 4
Green and red indicator illuminated: Increment
actions on low and high level.
V 5
Red indicator light for wire feed in manual
mode when BT 12 is pressed.
V 6
Green indicator illuminated: automatic fi ller
wire operation according to programmed pa-
rameters.
V 7
Green indicator light for variation in amplitude
overrides
V 8
Green indicator light for variation in overrides
over time
V 9
Green indicator light shows AVC is operating
V 10
Red indicator light shows AVC is suspended
V 11
Green indicator light for the operation of the "hot
wire" current.
V 12
Red indicator light for the suspension of the
"hot wire" current.
BT 1
Push button for line toggling on the display.
BT 2
Push button to move down in the WP or pro-
gram list or to decrease a numeric value. If
held down for more than 1 second, automatic
mode is applied.
BT 3
Push button to move up in the WP or program list
or to increase a numeric value. If held down for
more than 1 second, automatic mode is applied.
BT 4
Out of cycle: Toggles between simulation cy-
cle or arc cycle (coupled with V1 and V2).
BT 5
Loops round three options regarding increments:
high level or both levels (coupled with V3 and V4).
Item Function
BT 6 Out cycle : Press the button BT 6 “I-” of
the remote control pendant during several
seconds.
On the display of the remote control pendant
appears:
>IPAdress
Tacho
Select “IP Adress” with the button BT 1.
Confi rm the selection with the button BT 3
“N+”.
Modifi cation of the IP address. The IP address
is in the form of four numeric blocks that can
be modifi ed by BT 2 and BT 3. Moving from
one block to another is effected by a pulse on
BT 1. Once you have reached the last block,
pressing once more on BT 1 stores the new
entry in memory and terminates the IP address
modifi cation procedure.
In cycle: Decrementation of the weld current
level selected with BT 5.
BT 7
In cycle: Incrementation of the weld current
level selected with BT 5.
BT 8
Has two functions.
Out of cycle: carries out manual rotation in
reverse at slow speed if pressed and held for 1
second, medium speed for 2 seconds, then fast
speed.
In cycle: decrements the rotation speed on
the levels selected by BT 5.
BT 9
Has two functions.
Out of cycle: carries out manual forward rota-
tion at slow speed if pressed and held for 1
second, medium speed for 2 seconds, then fast
speed.
In cycle: decrements the rotation speed on
the levels selected by BT 5.
BT 10
Has two functions.
Off cycle in automatic mode (V6 lit): feeds
wire forward manually at slow speed if pressed
and held for 1 second, medium speed for 2 sec-
onds, then fast speed.
Off cycle in manual mode (V 5 lit): feeds the
wire quickly forward on fi rst press. Stops the
wire feed when pressed again.
In cycle: increments the wire feeding speed
level selected with BT 5.
BT 11
Has two functions.
Out of cycle: feeds wire manually in reverse
at slow speed if pressed and held for 1 second,
medium speed for 2 seconds, then fast speed.
In cycle: Decrement the wire feeding speed
level selected with BT 5.
BT 12
Toggles between
Wire feed in automatic mode (indicator -
lamp V 6 lit).
Wire feed in manual mode (indicator -
lamp V 5 lit).
