THE ART OF WELDING
P6 HW
46-100 PN-0110008 Rev. 12
Description of controls4. 4.
Front control and connection panel4. 4. 1.
Item Description
FA 2 Remote control unit connection.
FA 3 Connection of the rotation system.
FA 4 Connection of the wire feeder.
FA 5 Connection of the command cable of a manual torch or of a type MW welding head.
FA 7 Connection of a second gas (option).
FA 9 Connection of the torch shielding gas.
FA 10 Earth cable connection.
FA 11 Connection of the torch current cable.
FA 12 Coolant outlet connection 1.
FA 13 Coolant return connection 1.
FA 14 Connection of the PC interface (RJ45).
FA 15 Connection of the USB key.
FA 16 Short press: a ticket is printed summarising the welding carried out.
Long press (> 2 s): print-out of the program selected.
FA 17 Indicator light on when USB key busy with reading/writing.
Do not remove the USB key when the light is illumi-
nated.
FA 18 Write command on the USB key. (WP export + ticket).
FA 19 Read command on the USB key.
(WP import).
FA 26 Work piece voltage connection.
FA 27 Connection of arc height and oscillation.
FA 28 Positive connection of the "hot wire" current source.
FA 29 Negative connection of the "hot wire" current source.
