Technical characteristics3. 4.
Mains power supply
Three-phase + earth
400 V/415 V ± 10%
50 or 60 Hz
Input current 25 A (400 V)
No-load voltage 78V
Insulation class F
Protection rating
IP 23S (touchscreen closed)
IP 20 (touchscreen open)
Welding current range 5 to 520 A
Current regulation ± 1% for I > 100 A and ± 1 A for I ≤ 100 A
Duty cycle
Welding current 520 A at 60% 420 A at 100%
Hot wire current 140 A to 100 %
Current pulsing range
520 A range: 5 to 520 A
Time: 10 to 3300 ms
Controlled movements
Head rotation
Wire feeder
Arc height - AVC
Oscillation - OSC
Speed accuracy
± 1% for Vp ≥ ¼ V
max
(Vp = programmed speed)
± 2 % for Vp < ¼ V
max
Controlled gases Torch gas, second gas (optional)
Source cooling Forced ventilation
Torch cooling By external coolant
Actual value display in-cycle
Permanent power source output voltage and welding current
display (if equipped with optional remove control or touch-
screen)
WPs in memory maximum 200
Sectors per program maximum 99
Backup and loading On USB fl ash drive
Dimensions
800 x 470 x 950 mm (L x W x H) without trolley
1060 x 530 x 1145 mm with trolley
Weight
138 kg
without trolley
154 kg with trolley
Standards EN 60974-1 and EN 60974-10
The EMC classifi cation in accordance with EN 60974-10 has been produced according to class A.
The heating tests have been carried out at ambient temperature. The duty cycle at 40 °C has been determined
by simulation.
