THE ART OF WELDING
P6 HW
PN-0110008 Rev. 12 79-100
Spare parts for P6 HW remote control6. 2. 6.
Fig 6.12 and Fig 6.13
Item. Order Code Description
- 0026169102 Remote control complete (without emergency stop)
- 0026169103 Remote control complete (with emergency stop)
- 9000563323 Remote control plug
- 9000563326 Crimp contact for the plug
1 9000502015 Green light
2 9000502019 Red light
3 9000542083 Green button for the remote control
4 9000542082 Red button for the remote control
5 9000542081 Black button for the remote control
6 0028049100 Remote control module
7 0028209200 Display adapter
8 00503026 Display 4 x 20 characters
9 0028319100 Assembled fl exible card for P6 pendant
