Polysoude P6 HW - Fig. 4.20 - Remote Control Unit with Emergency Stop

THE ART OF WELDING
P6 HW
1
44-100 PN-0110008 Rev. 12
Fig. 4.20 - Remote control unit with emergency stop
The rear connector 44–pin connector allows the drive. Here the representation of the connector with the I / O
available.
