2-7

Cabinet Dimensions
PFC-6800 Cabinet DimensionsFigure 1.
27.32 “
26.00 “
4.41”
3.75“
17.60”
18.91”
BOTTOM
RIGHT SIDE
DEPTH
DEPTH
TOP
LEFT SIDE
DWG #602-1
