Potter PFC-6800 - Cabinet Wiring Connections

2-8

Cabinet Wiring Connections
PFC-6800 Cabinet WiringFigure 2.
DWG #602-2
120VAC 50Hz-60Hz
240VAC 50Hz-60Hz
Connect to separate
unswitched AC circuits
Non-power limited
relay connection
High voltage
phone connections
Optional
UD-1000 DACT
Power
limited wiring
Power limited
wiring
Optional CA-6500
Class A Expander
120 240
120/240 VAC
Jumper Position
Non-power
limited battery
connection
