Potter PFC-6800 - Serial Parallel Gateway Installation (SPG-1000)

3-41

Setting Addresses
dip switch S1
(Refer to the "P-Link Addresses" table shown earlier in this section for DIP
switch programming.)
FIB-1000 Back Panel Showing Dip Switch LocationFigure 49.
Serial Parallel Gateway Installation (SPG-1000)



SPG-1000 Serial Parallel Gateway Board & Rack MountFigure 50.
SPG-1000 Wiring to Control Panel ExampleFigure 51.
DWG #608-24
Dip Switches
P-Link
Connections
S1
DWG #608-16
DWG #608-15
DWG #608-26
P-Link
-
+ A B
P-Link from
control panel
Example:
Powered by
control panel
