Potter PFC-6800 - P-Link Devices

3-32

P-Link Devices


128 P-Link devices
NoteSection 6:
PSN-1000/PSN-1000(E) – Installing, Operating & Programming,
Conguration Characteristics
y
y
y
Maximum Wire Resistance Formula
load

(Total Annunciator Alarm Current) x (Wire Resistance) < 6 Volts
P-Link Class B Wiring ExampleFigure 31.
To the next device
- + A B
Expansion
Device
- + A B
P-LINK 2
- + A B
Panel
Connection
Expansion
Device
P-LINK 1
- + A B
Note

DWG #602-11
