From FACP or the previous
addressable device on the SLC loop
To the next addressable device
S+ S+
S- S-
DWG #593-10
Connecting Analog Detectors
i.e. AB-6
Analog Detector Wiring ExampleFigure 10.
Connecting Addressable Modules
Conventional Initiating Zones (CIZM-4) Class A
CIZM-4, Class AFigure 11.
Note: The resistance of external wiring shall be less that 100Ω.
The capacitance of external wiring shall be less than 1 micro farads.
From FACP or
Previous Module
o Next Module
From FACP
or Previous Module
To Next
Module
24-
24+
S-
S+
SLC Loop
LED
JP1
Select Style D
Conventional
Detector
_
+
_
+
_
+
Conventional Initiating Zone Module
Model No. CIZM-4
A-
A+
B-
B+
DWG #593-11
Notes:
1.
2.
3. trouble condition
MUST
4.
To Next Page
