NOTES:
• Maximum applicable capacity is indicated in the case of using a 4-pole standard
motor (200 and 400V classes are based on 220 and 440V, respectively).
• For the rated capacity, 200 and 400V class input capacities are based on 220 and
440V, respectively.
• The rated output current is limited depending on the setup of carrier frequency
(Cn.4).
• The output voltage becomes 20~40% lower during no-load operations to protect the
drive from the impact of the motor closing and opening (0.4~4.0kW models only).
• Dual rating is supported except IP66/NEMA 4X.
