MODBUS COMMUNICATION
227
Summary of Modbus Addresses
Common Area
Modbus Address
Parameter
Scale
Units
R/W
Data Values
Decimal
Hexadecimal
40000
0h0000
Inverter Model
-
-
R
B: SD300
40001
0h0001
Drive Power Rating
-
-
R
0: 0.75kW
1: 1.5kW
2: 2.2kW
3: 3.7kW
4: 5.5kW
5: 7.5kW
6: 11kW
7: 15kW
8: 18.5kW
9: 22kW
40002
0h0002
Drive Input Voltage
-
-
R
0: 220VAC
1: 400VAC
40003
0h0003
SW Version
-
-
R
(Ex) 0x0100: Version 1.0
(Ex) 0x0101: Version 1.1
40005
0h0005
Reference
Frequency
0.01
Hz
R/W
Starting Frequency to Max
Frequency
40006
0h0006
Start / Stop
Command
-
-
R/W
Bit 0: Stop
Bit 1: Forward Start
Bit 2: Reverse Start
Bit 3: Fault Reset
Bit 4: Emergency Stop
-
Bit 5: Not used
R
Bit 6 – 8: Setpoint
Introduction
0: Local
1: Start/Stop-1
2: Start/Stop-2
3: RS485 integrated
4: Communications
Option
5: PLC Option
