228
MODBUS COMMUNICATION
Modbus Address
Parameter
Scale
Units
R/W
Data Values
Decimal
Hexadecimal
Bit 9 – 14: Reference
Frequency
0: Local Reference
1: Not used
2: Step frequency 1
3: Step frequency 2
4: Step frequency 3
5: Step frequency 4
6: Step frequency 5
7: Step frequency 6
8: Step frequency 7
9: Step frequency 8
10: Step frequency 9
11: Step frequency 10
12: Step frequency 11
13: Step frequency 12
14: Step frequency 13
15: Step frequency 14
16: Step frequency 15
17: Up Speed
18: Down Speed
19: Constant
20 – 21: Reserved
22: Analog V1
23: Analog I1
24: Analog V2
25: Analog I2
26: Reserved
27: RS485
28: Communication
Option
29: PLC Option
30: Fix Frequency
31: PID
Bit 15: Not used
40007
0h0007
Acceleration Time
0.1
Sec
R/W
-
40008
0h0008
Deceleration Time
0.1
Sec
R/W
-
40009
0h0009
Output Current
0.1
A
R
-
40010
0h000A
Output Frequency
0.01
Hz
R
-
40011
0h000B
Output Voltage
1
V
R
-
40012
0h000C
DC Bus Voltage
1
V
R
-
40013
0h000D
Output Power
0.1
kW
R
-
