DESCRIPTION OF PROGRAMMING PARAMETERS
105
Screen
Description
Default
value
Modbus Address
Function
DEC
HEX
St3
[1]
Multi-step speed
frequency 3
30.00Hz
47943
0h1F07
See group Basic Functions (bA),
parameter St3.
CUr
Output current
-
47944
0h1F08
These values depend on drive
characteristics.
rPM
Motor revolutions
per minute
-
47945
0h1F09
dCL
Inverter direct
current voltage
-
47946
0h1F0A
vOL
Inverter output
voltage
-
47947
0h1F0B
LuT
Out of order signal
-
47948
0h1F0C
drC
Select rotation
direction
-
47949
0h1F0D
Group 1: Drive → dr
Screen
Description
Default
value
Range
Function
Set
on
RUN
0.00
[1]
Local speed
0.00Hz
dr.19 to
dr.20
Set the motor speed value. Minimum value is
set in dr.19 and the maximum value in dr.20.
YES
dr.2
Local torque
0.0%
-180.0
to
180.0%
Set the torque value of the motor.
YES
ACC
[1]
Acceleration
ramp
20.0s
0.0 to
600.0s
Set the acceleration ramp 1, in seconds. This
ramp will be set according to the requirements
of each process.
YES
dEC
[1]
Deceleration
ramp
30.0s
0.0 to
600.0s
Set the deceleration ramp 1, in seconds. This
ramp will be set according to the requirements
of each process.
YES
[1] Displayed when an LCD keypad is in use.
