DESCRIPTION OF PROGRAMMING PARAMETERS
Group 2: Basic Functions → bA
Screen
Description
Default
value
Range
Function
Set
on
RUN
bA.1
Alt Speed
Ref
None
0 to 6
Select the auxiliary speed reference source for
the speed sum to the main reference,
according to the following table:
OPT.
DESCR.
FUNCTION
0
None
The reference will be
introduced by using the
keypad.
1
V1
Reference will be
introduced through the
voltage analog input 1.
3
V2
Reference will be
introduced through the
voltage analog input 2.
4
I2
Reference will be
introduced through the
current analog input 2.
6
Pulse
Reference will be
introduced through the
Pulse input.
NO
bA.2
[2]
Aux
calculation
type
M+(GA)
0 to 7
Adjust the equation to calculate the speed
reference. In order to do this, the present
reference source, the auxiliary reference
(bA.1) and the gain for this reference (bA.3)
are used.
Notice that options 4-7 could result in
references with positive or negative sign
(forward or reverse operation) even when
unipolar analog inputs are used.
NO
[
2
] These parameters will only be displayed if bA.1 is not set to 0 (None)
