COMMONLY USED CONFIGURATIONS
17. COMMONLY USED
CONFIGURATIONS
NOTICE
The following instructions are based on the assumption that all parameters are set
to the factory default values. Results may be different if parameter values have
been modified. In this case, set all parameters back to their default value and follow
the instructions.
Start/Stop command and speed setting from
keyboard
Parameter configuration
Parameter
Default
value
Description
Set value
0.00
0.00Hz
Frequency reference
x.xxHz (Set the frequency reference).
ACC
20.0 seg
Acceleration time
10.0 sec
dEC
30.0 seg
Deceleration time
10.0 sec
drv
1
Start/Stop control
0: Start/Stop from keyboard.
frq
0
Frequency setting
mode
0: Reference will be introduced from keyboard.
Ad.8
0
Stop mode
0: Stop with deceleration ramp.
1: DC brake to stop.
2: Free run to stop.
4: Regenerative brake to stop.
Ad.10
0
Start after low voltage.
0: NO (Drive does not start after power loss).
1: YES (Drive starts after power loss).
Ad.24
0
Use frequency limit
0: NO (Limits are set by maximum frequency and
start frequency).
1: YES (Limits are set by the higher and lower
frequency limits).
Ad.25
0.50Hz
Frequency lower limit
0.00Hz
17
