Power Electronics SD300 Series User Manual

POWER ELECTRONICS
SD300
COMMONLY USED CONFIGURATIONS
291
Parameter
Default
value
Description
Set value
Ad.26
50.00Hz
Frequency higher limit
50.00Hz
bA.13
(*)
Motor Current
?A (See motor plate).
dr.14
(*)
Motor rated power
0.2
0.2kW
…
…
5.5
5.5kW
7.5
7.5kW
dr.15
0
Torque boost
0: Manual torque (Both directions can be
configured separately, in dr.16 ➔ ‘Start torque in
forward direction’ and in dr.17 ➔ ‘Start torque in
reverse direction’).
1 and 2: The drive automatically calculates the
voltage to apply at the start using the motor
parameters.
dr.18
60.00Hz
Motor frequency
50.00Hz
dr.19
0.50Hz
Start frequency
0.10Hz
dr.20
60.00Hz
Max speed limit
50.00Hz
dr.93
0
Parameter initialization
1: Set parameters back to their factory value
(only if required)
dr.97
2.x
Software version
-
Cn.4
3kHz
Modulation frequency
5kHz
(*) This value depends on the motor setting.
