COMMONLY USED CONFIGURATIONS
295
Start/Stop command by terminals and speed
setting by analogue input
Parameter configuration
Parameter
Default
value
Description
Set value
0.00
0.00Hz
Frequency reference
x.xxHz (Reference visualization).
ACC
20.0 seg
Acceleration time
10.0 sec
dEC
30.0 seg
Deceleration time
10.0 sec
drv
1
Start/Stop control
1: Start/Stop from terminals FX – Forward o Rx –
Reverse.
frq
0
Frequency setting
mode
2: Reference will be introduced through analogue
V1.
5: Reference will be introduced through analogue
I2.
Ad.8
0
Stop mode
0: Stop with deceleration ramp.
1: DC brake to stop.
2: Free run to stop.
4: Regenerative brake to stop.
Ad.10
0
Start after low voltage.
0: NO (Drive does not start after power loss).
1: YES (Drive starts after power loss).
Ad.24
0
Use frequency limit
0: NO (Limits are set by maximum frequency and
start frequency).
1: YES (Limits are set by the higher and lower
frequency limits).
Ad.25
0.50Hz
Frequency lower limit
0.00Hz
Ad.26
50.00Hz
Frequency higher limit
50.00Hz
bA.13
(*)
Motor Current
?A (See motor plate).
dr.14
(*)
Motor rated power
0.2
0.2kW
…
…
5.5
5.5kW
7.5
7.5kW
(*) This value depends on the motor setting.
