Power Electronics SD300 Series User Manual

SD300
POWER ELECTRONICS
128
DESCRIPTION OF PROGRAMMING PARAMETERS
Group 3: Expanded Functions → Ad
Screen
Description
Default
value
Range
Function
Set
on
RUN
Ad.1
Acceleration
pattern
Linear
Linear
S-curve
Set the type of acceleration and deceleration
depending on the application:
OPT.
DESCR.
FUNCTION
0
Linear
The output frequency is
constant and increases/
decreases linearly.
1
S-curve
Used in applications
which require a soft
acceleration/
deceleration, such as
lifting loads. The S curve
index can be set from
parameters Ad.3-Ad.6.
NO
Ad.2
Deceleration
pattern
Ad.3
[7]
S curve start
acceleration
slope
40%
1 to
100%
Set the curve whenever the
acceleration/deceleration pattern is defined
as S curve. It is used to set the S curve
curvilinear relation when starting the
acceleration.
NO
Ad.4
[7]
S curve stop
acceleration
slope
40%
1 to
100%
Set the curve’s ramp once the
acceleration/deceleration pattern has been
defined as S Curve. It is used to set the S
Curve curvilinear relation when ending the
acceleration.
NO
Ad.5
[8]
S curve start
deceleration
slope
40%
1 to
100%
Set the curve whenever the
acceleration/deceleration pattern is defined
as S curve. It is used to set the S curve
curvilinear relation when starting the
deceleration.
NO
Ad.6
[8]
S curve stop
deceleration
slope
40%
1 to
100%
Set the curve’s ramp once the
acceleration/deceleration pattern has been
defined as S Curve. It is used to set the S
Curve curvilinear relation when ending the
deceleration.
NO
[
7
] These parameters will only be displayed if Ad.1 is set to1 (S-curve).
[
8
] These parameters will only be displayed if Ad.2 is set to 1 (S-curve).
