Power Electronics SD300 Series User Manual

POWER ELECTRONICS
SD300
COMMONLY USED CONFIGURATIONS
307
Permanent Magnet Synchronous Motor control
Parameter configuration by funcionalities
1. Basic Parameters drive/motor
These parameters are the necessary ones to correctly set the nameplate
of the motor and the configuration of the drive. It is mandatory all
parameters to be introduced since the thermal model and internal
calculation depend on these parameters for the proper operation of the
vector sensorless control.
Parameter
Default
value
Description
Set value
dr.9
V/Hz
Control mode
6 PM Sensor-less
dr.14
-
Motor capacity
Depends on the motor capacity
dr.18
60.00Hz
Base frequency
Depends on the PM motor capacity
dr.20
60.00Hz
Maximum frequency
Depends on the PM motor capacity
bA.11
-
Motor pole number
4
bA.13
-
Rated motor current
Depends on the motor capacity
bA.15
0V
Motor-rated voltage
220/380/440/480
bA.16
-
Motor efficiency
Depends on the motor capacity
bA.19
380V
Motor input voltage
220/380
2. Internal motor parameters
These parameters are meassured by the function “Auto-tuning”. To
perform the autotuning, it is necessary the parameter bA.20 to be set at 7.
The drive will perform diverse tests to extract the value of the parameters.
