Power Electronics SD300 Series User Manual

POWER ELECTRONICS
SD300
TECHNICAL CHARACTERISTICS
19
3. TECHNICAL
CHARACTERISTICS
SD300 SERIES
INPUT
Power ranges
0.4kW – 2.2kW 230V – Single Phase
0.4kW – 22kW 230V – 3-Phase
0.4kW – 30kW 400V – 3-Phase
Voltage range
230V: 200-240V Single Phase / 3-Phase (-
15%/+10%)
400V: 380V-480V 3-Phase (-15%/+10%)
EMC Filter
C2
[1]
(First environment)
C3 (Second environment)
OUTPUT
Overload capacity
150% for 60sec. (Heavy duty)
120% for 60sec. (Normal duty)
[2]
200% for 4sec. (Heavy Duty)
Control Method
V/f, Slip compensation, Sensorless vector,
PMSM VC
[3]
Frequency Setting
Resolution
Digital command: 0.01Hz / Analog command:
0.06Hz (maximum frequency: 60Hz)
Frequency Accuracy
1% of the maximum output frequency
V/F Pattern
Linear, Quadratic, User V/F
Output frequency
0-400Hz (Sensorless: 0-120Hz)
Torque Boost
Manual/Automatic torque boost
OPERATION
Operation Mode
Keypad / Terminal / Communication option
selectable
Frequency Setting
Analog: -10~10[V], 0~10[V], 4~20[mA] / Digital:
Keypad, Pulse train input
[
1
] Option external RFI filter required
[
2
]Only available for IP20
[
3
]Consult with Power Electronics before installing with this type of motors.
