SD300

POWER ELECTRONICS

276

ACCESSORIES

Conduit Kit

UL open type is offered by default. To meet UL enclosed type1, this kit must

be installed.

Optional conduit kit

Ask for the conduit module that corresponds to your drive frame for NEMA1

compliance:

Code

Frame

SD3EBF1

1N & 2N

SD3EBF2

3N & 4N

SD3EBF3

5N

SD3EBIP6F1

1F

SD3EBIP6F2

2F

SD3EBIP6F3

3F

SD3EBF4

4

SD3EBF5

5

SD3EBF6

6
